Lofrans SX7 Vertical Windlass

Compact round base design

Marine AISI 316L Stainless Steel construction

Independent gypsy and drum operation

Manual chain release

Chain counter magnet pre-installed as standard

Marine anodised aluminium gearbox

Available electric (DC or AC) and hydraulic motors

Chain pipe included in the package.

Dual direction solenoid pack

Handle

Gypsy for chain

QR code card for Instruction Manual

Complete Windlass.

Chain gypsy.

Dual Direction Solenoid pack.

Winch handle.

CD/ Instruction Manual.

Construction	316L Stainless Steel	316L Stainless Steel	316L Stainless Steel
Motor Size	3500W	4000W	Hydraulic - 8cc
Volts	24	230/400
Amps under load	240
Maximum Instant Lift (kg)	3000	3100	3700
Lifting Working Load (kg)	800	840	1000
Line speed (m/min)	7	8	10
Max line speed (m/min)	9	10	10
Net Weight (kg)	160	160	145
Hydraulic Pressure (bar)			200
Hydraulic Flow (lt/min)			32

Construction	Inox - 316	Inox - 316	Inox - 316
Motor Size	3500 W	4000 W	Hydraulic - 8cc
	24v	230-400v
Prices	16,128.16 € Sale Price 14,515.35 €	16,034.78 € Sale Price 14,431.30 €	16,085.78 € Sale Price 14,477.20 €
Clockwise rotation
12mm ISO 13mm DIN	636459	636520	636526
14mm	636518	636522	636524
Counter Clockwise rotation
12mm ISO 13mm DIN	636464	636521	636527
14mm	636519	636523	636525
