Available in two different configurations, for installation in the port or starboard side of the transom
IP67 protective cover for the motor
Marine anodised aluminium gearbox
Automatic free fall operation with the push of a button
Automatic stop function for carefree anchoring
For use with 12/14/16 mm 3-strand or leaded rope
Compact design
Easy installation which needs very limited space (the motor/gearbox can rotate up to 180° at 60° increments)
Dual direction solenoid pack
Handle
Gypsy for rope
QR code card for Instruction Manual
Automatic stop
| Construction | Anodised Aluminium | |
|---|---|---|
| Motor Size | 600W | 900W |
| Power Supply | 12v | 12v |
| Maximum Pull (kg) | 630 | 700 |
| Working Load (kg) | 95 | 125 |
| Amps at Working Load | 65 | 80 |
| Line Speed at Working Load (m/min) | 18 | 20 |
| Max Line Speed (m/min) | 24 | 25 |
| Net Weight (kg) | 9 | 10 |
| Rope Size |
Motor | Part | ||
|---|---|---|---|---|
|
500w |
1,362.42 €
Sale Price 1,226.18 € 636645
|
||
|
800w |
1,627.34 €
Sale Price 1,464.60 € 636633
|
